Inspiron Desktops & All-in-One

Front:
2 USB 2.0 Type-A ports
1 USB 3.2 Type-A Gen 1 port
1 USB 3.2 Type-C Gen 1 port
1 Universal headset jack

Rear:
2 USB 2.0 Type-A ports with Power on/Wake support

1 SATA 2.0 slot
1 SATA 3.0 slot
1 PCIe x16 slot
1 PCIe x1 slot
1 M.2 2230 slot for WiFi and Bluetooth combo card
1 M.2 2230/2280 slot for PCIe solid-state drive
1 SD-card slot (optional)

Height (rear): 290.00 mm (11.42 in.)
Height (front): 290.00 mm (11.42 in.)
Width: 92.60 mm (3.65 in.)
Depth: 292.80 mm (11.53 in.)
Weight (minimum): 4.02 kg (8.86 lb)
Weight (maximum): 4.72 kg (10.41 lb)*

Front:
2 USB 2.0 Type-A ports
1 USB 3.2 Type-A Gen 1 port
1 USB 3.2 Type-C Gen 1 port
1 Universal headset jack


Rear:
2 USB 2.0 Type-A ports with Power on/Wake support

1 SATA 2.0 slot
1 SATA 3.0 slot
1 PCIe x16 slot
1 PCIe x1 slot
1 M.2 2230 slot for WiFi and Bluetooth combo card
1 M.2 2230/2280 slot for PCIe solid-state drive
1 SD-card slot (optional)

Height (rear): 290.00 mm (11.42 in.)
Height (front): 290.00 mm (11.42 in.)
Width: 92.60 mm (3.65 in.)
Depth: 292.80 mm (11.53 in.)
Weight (minimum): 4.02 kg (8.86 lb)
Weight (maximum): 4.72 kg (10.41 lb)*

Front:
2 USB 2.0 Type-A ports
1 USB 3.2 Type-A Gen 1 port
1 USB 3.2 Type-C Gen 1 port
1 Universal headset jack

Rear:
2 USB 2.0 Type-A ports with Power on/Wake support

1 SATA 2.0 slot
1 SATA 3.0 slot
1 PCIe x16 slot
1 PCIe x1 slot
1 M.2 2230 slot for WiFi and Bluetooth combo card
1 M.2 2230/2280 slot for PCIe solid-state drive
1 SD-card slot (optional)

Height (rear): 290.00 mm (11.42 in.)
Height (front): 290.00 mm (11.42 in.)
Width: 92.60 mm (3.65 in.)
Depth: 292.80 mm (11.53 in.)
Weight (minimum): 4.02 kg (8.86 lb)
Weight (maximum): 4.72 kg (10.41 lb)*

1 USB 3.2 Type-C Gen 2 port*
3 USB 3.2 Gen 1 ports with Power on/Wake-up support
1 HDMI-out 1.4b
1 HDMI-in 1.4b
1 power-adapter port

1 M.2 2230/2280 slot for PCIe solid-state drive
1 M.2 2230 slot for WiFi and Bluetooth combo card
1 SD-card slot

Without stand:
Depth: 41.80 mm (1.64 in.)
Width: 614.70 mm (24.20 in.)
Rear   Height: 399.74 mm (15.73 in.)
Front Height: 394.82 mm (15.54 in.)
Starting Weight (Touchscreen): 6.93 kg (15.27 lb)*
Maximum Weight (Touchscreen): 7.08 kg (15.60 lb)*
Starting Weight (Non-Touchscreen): 6.64 kg (14.63 lb)*
Maximum Weight (Non-Touchscreen): 6.79 kg (14.96 lb)*

With Isosceles stand:
Depth: 200.70 mm (7.90 in.)
Width: 603.70 mm (23.76 in.)
Rear   Height: 455.50 mm (17.93 in.)
Front Height: 455.50 mm (17.93 in.)
Starting Weight (Touchscreen): 7.26 kg (15.99 lb)*
Maximum Weight (Touchscreen): 7.41 kg (16.33 lb)*
Starting Weight (Non-Touchscreen): 6.99 kg (15.40 lb)*
Maximum Weight (Non-Touchscreen): 7.14 kg (15.73 lb)*

Open Pop-Up Camera height: 25.00 mm (0.98 in.)

3 USB 3.2 Gen 1 ports with Power on/Wake-up support
1 USB 3.2 Gen 2 port with PowerShare
1 USB 3.2 Type-C Gen 2 port (Side)
1 HDMI-out 1.4b
1 HDMI-in 1.4b
1 RJ45 Ethernet port
1 Universal headset jack
1 power-adapter

1 M.2 2230/2280 slot for PCIe solid-state drive
1 M.2 2230 slot for WiFi and Bluetooth combo card
1 SD-card slot

Without stand:
Depth: 1.58 in. (40.20 mm)
Width: 21.86 in. (542.70 mm)
Rear Height: 15.17 in. (358.54 mm)
Front Height: 13.92 in. (353.82 mm)
Starting Weight (Touchscreen): 11.39 lb (5.17 kg)
Maximum Weight (Touchscreen): 11.72 lb (5.32 kg)
Starting Weight (Non-Touchscreen): 11.32 lb (5.14 kg)
Maximum Weight (Non-Touchscreen): 11.65 lb (5.29 kg)

With Y stand:
Depth: 7.85 in. (199.55 mm)
Width: 21.22 in. (539.11 mm)
Rear height: 16.31 in. (414.30 mm)
Front Height: 16.31 in. (414.30 mm)
Starting Weight (Touchscreen): 11.94 lb (5.42 kg)
Maximum Weight (Touchscreen): 12.25 lb (5.56 kg)
Starting Weight (Non-Touchscreen): 11.87 lb (5.49 kg)
Maximum Weight (Non-Touchscreen): 12.20 lb (5.54 kg)

With Isosceles stand:
Depth: 7.90 in. (200.70 mm)
Width: 20.92 in. (531.50 mm)
Rear height: 16.31 in. (414.30 mm)
Front Height: 16.31 in. (414.30 mm)
Starting Weight (Touchscreen): 12.09 lb (5.49 kg)
Maximum Weight (Touchscreen): 12.42 lb (5.64 kg)
Starting Weight (Non-Touchscreen): 12.03 lb (5.46 kg)
Maximum Weight (Non-Touchscreen): 12.36 lb (5.61 kg)

1 USB 3.2 Type-C^® Gen 2 port
2 USB 3.1 Gen 1 ports with Power on/Wake-up support
1 USB 3.1 Gen 2 port with PowerShare
1 HDMI 1.4b port
1 HDMI-in 1.4b port
1 power-adapter port
1 RJ45 Ethernet port

Without Stand
Height: Rear 358.50 mm , Front 353.80 mm
Width: 542.70 mm
Depth: 40.20 mm
Starting weight: Touchscreen 5.27 kg (11.62 lbs.), Non-Touchscreen 5.27 kg (11.62 lbs.)

With Arch Stand
Height: Rear 411.90 mm , Front 411.90 mm
Width: 542.70 mm
Depth: 199.55 mm
Starting weight: Touchscreen 5.52 kg (12.17 lbs.), Non-Touchscreen 5.49 kg (12.10 lbs.)

With Triangle Stand
Height: Rear 411.90 mm, Front 411.90 mm
Width: 542.70 mm
Depth: 200.69 mm
Starting weight: Touchscreen 5.52 kg (12.17 lbs.), Non-Touchscreen 5.49 kg (12.10 lbs.)

Rear Cover / Mid Frame - Plastic Resin
Y-stand exterior - Plastic Resin
Isosceles stand exterior - Die Cast (Aluminium or Zinc) and painted
